Brief Description
Our Micro Powder Packing Machine is available in two types: valve and open. It offers advanced electronic measurement with adjustable feeding and speed control.
Application
It finds wide application across various industries including calcite (GCC), carbon black, talc, feldspar, kaolin, bentonite, Al(OH)3, silicon carbide, quartz, barite, and food processing.
Main Specification
CBF-159A Valve-port Packing Machine
| SPECIFICATIONS | |
| Type | CBF-159A |
| Bag weight | 3-50KG |
| Accuracy | ±0.2～0.5% |
| Filling speed | 3-5 bags/min，（25KG） |
| Power | 380V 50HZ，4KW |
| Air consumption | P≥0.6Mpa，Q≥0.4m3/min |
| Equipment weight | 420KG |
| Dimension | 800mmL*1400mmW*1850mmH |
CBF-159B Valve-port Packing Machine
| SPECIFICATIONS | |
| Type | CBF-159B |
| Bag weight | 1-60KG |
| Accuracy | ±0.1~0.3% |
| Filling speed | 3-5 bags/min,(25KG) |
| Power | 380V 50HZ ,8KW |
| Air consumption | P≥0.6Mpa, Q≥0.4m3/min |
| Equipment weight | 900KG |
| Dimension | 850mmW x 1500mmL x 2155mmH |
CBC-200C Open-valve Packing Machine
| SPECIFICATIONS | |
| Type | CBC-200C |
| Bag weight | 1~50kg |
| Accuracy | ±0.2~0.5% |
| Filling speed | 3~5 bags/points (25kg) |
| Power | 380V 50Hz 3Kw |
| Air consumption | P≥0.6MPa Q≥0.4m3/min |
| Equipment weight | 550kg |
| Dimension | 3300mmL x 2000mmW x 2700mmH |
CBC-1000D Tonnage-sack Packing Machine
| SPECIFICATIONS | |
| Type | CBC-1000D |
| Bag weight | 1-2000 |
| Accuracy | ±0.2%-0.5% |
| Filling speed | 7-10 package/points 1 ton |
| Power | 380V 50Hz 3kw |
| Air consumption | P≥0.6mPa Q≥0.4m3/min |
| Equipment weight | 850kg |
| Dimension | 800mmL*1800mmW*2500mmH |
Other Main Products
Clirik’s European Coarse Powder Mill is used in industries like metallurgy and construction, crushing rocks up to 320 MPa into coarse powder, with most particles under 3mm.
Clirik’s High Pressure Suspension Grinding Mill manages minerals up to hardness 9.3 and low moisture, offering fineness control from 50 to 325 meshes.
The CLUM Ultrafine Mill is used in industries like chemicals and metallurgy, specializing in producing fine powders for papermaking, coatings, and plastics. It processes materials like calcite, marble.
Clirik’s Enhanced Roller Grinding Mill processes minerals up to Moh’s hardness 6, used in various industries with adjustable output from 50 to 325 meshes.
